Tilt & Turn Windows

HOW DO TILT AND TURN WINDOWS WORK?

Tilt and turn windows work by the simple turning of a single handle. There are three different positions for the handle, each of which allows unique functionality. When the handle is pointing upward and the window is closed, at least five steel locking pins keep the window securely shut.

When the handle is turned by 90 degrees, into the horizontal position, the window starts operating differently than a door. The hinge in the upper corner is disconnected. At the same time, a hinge in the other bottom corner of the vent is connected to the vent. The vent suddenly tilts inwards, held by the hinges the bottom corners. That is possible because of an ingenious design: One of the hinges on the lower corner operates in two directions, supporting both tilt and turn. The other two hinges support only tilt or turn but are only connected to the vent if the window handle is in a certain position. When the handle is turned by 180 degrees pointing downwards, the window functions a lot like a normal door. In this position, the locking pins are unlocked and the window vent turns open, held by hinges on one side of the window. There is one hinge on the upper corner and one on the lower corner, just like you would see it on a regular door.

With that, the whole window can open like a door or just tilt inward by 10 to 15 degrees, moving along the hinges on the bottom of the window and allowing easy ventilation without having to worry about intruders or weather changes.

6.1590 x 700

NOTE: WINDOW MUST BE FIRMLY IN CLOSE POSITION BEFORE CHANGING FROM ONE OPERATION TO THE OTHER (I.E FROM TILT TO TURN OR VICE VERSA). ONCE WINDOW IS UNLOCKED KEY MUST STAY IN UNTIL RETURNED TO LOCKED POSITION.

CLOSED POSITION

The window closes easily with one turn of the handle engaging all the locks (up to 8 depending on the size of the window) at the same time. This position creates a seal that keeps out sound, heat or cold. The window can be deadlocked in this position, using a key.



1
2

TILT POSITION

The window can be tilted inwards for optimal, draft-free ventilation. This position is restricted to no more than 150mm and is secured to prevent intruders from getting in, leaving you and your property safely protected. The tilt position of a Tilt & Turn window is best for ventilation. The outside air is channelled through the sides of the window, while hotter air that rises escapes through the top.

TURN POSITION

The turn position allows the window to be opened fully, depending on the position of the window it could be up to 180 degrees. Restrictors are available that allow you to restrict just how much your window will open depending on your needs. In this position, the window can be easily cleaned from the inside of your home.

3
